WJSL-LGD165A “LANG CHAO” SERIES SMART GARDEN LAMP BOLLARD LAMP
Smart Security Monitoring
● Security surveillanc
● Image algorithm
Smart Lighting
● Adaptive color temperature and brightness adjustment based on environmental data
Product Features
●Application:
Among its many characteristics, the "LANG CHAO" series basic smart garden lamp 1 is a highly integrated smart pole lamp with digital IP audio, smart illumination, and smart safety and surveillance. It is suitable for smart city applications in high-end outdoor areas such as parks, business districts, commercial streets, and smart communities.
● Lamp Features:
/A top deep-cover structure with downward-directed light is a feature of the lighting section. To avoid glare and provide superior illumination, each LED emits directed light.
/The ambient lighting structure uses an upward-tilted wave-pattern hollow design, serving as an artistic decorative highlight. It can adapt lighting effects based on scene requirements or intelligent data, while providing excellent glare control and perfect visual comfort.
/Lamp pole audio (optional): The lamp can be equipped with built-in IP digital audio according to project needs, with adaptive volume adjustment based on the scene environment.
/The top camera can rotate 360° horizontally and is fixed with screws after adjustment to the desired angle.
/Built-in Intelligent controller connects to the smart central control system, allowing adjustment of color temperature and brightness changes under energy-saving mode according to system requirements.
/Installation: flange base installation with an embedded foundation.
● Main Materials:
/The lamp head and wave-pattern structure are built of high-precision integrated aluminum alloy casting, while the lamp body is primarily composed of metal tubing. The surface is secured with 304 stainless steel fasteners and treated with a premium AkzoNobel glittering silver-gray coating that is resistant to discoloration for five years.
/Excellent light transmission, robust self-cleaning capabilities, anti-aging PC tube, and high transparency.
|
Smart safety & surveillance (optional) |
Spherical surveillance camera /Dome surveillance camera(see page 18: data collection & safety & surveillance camera) |
|
Artistic ambient lighting |
RGBW color-changing light-transmission effect; can also be connected to smart systemsto change light colors as needed |
|
Smart lighting |
Color temperature options: a. single cololb.2200K-5000KC.RGBWControl method: DMX512 or switch type;Beam angle: 120°:Color rendering index: Ra > 80 |
|
Smart lP audio |
Built-in amplifier diqital audio. Peak Power: 60W Speaker units: 4×4 inch full-range + 1×0.5 inch tweeter (see page 16: network IP audio) |
|
Intelligent control box |
Built-in Intelligent controller with multi-channel Ethernet gateway integration |
|
Other confiqurations (optional) |
a.one-touch help b.visual algorithm integration c. WiFi transmission |
|
Protection level |
IP65 |
|
Operating voltage |
AC220V |
|
Power |
Lighting 60W, ambient light 20W, security camera 15W, audio 60W |
